Supported in terms of both hardware and software. Not available for purchase.
| End-of-life | |
| End of sales | Jul 1, 2022 |
| End of hardware serviceability 1 2 | Jul 1, 2026 |
| End of software support 1 | Jul 1, 2027 |
| Processor | |
| Model | Intel Xeon E5-1660 v4 |
| Base frequency | 3.2 GHz |
| Number of cores | 8 |
| Upgrade | Up to 18 cores @ 2.1 GHz |
| Memory | |
| Size | 128 GB |
| Type | DDR4, ECC, REG |
| Frequency | 2666 MHz |
| Upgrade | Up to 256 GB |
| Storage | |
| Catalog drive capacity | 960 GB, SSD |
| Data drive capacity (raw) | 96 TB, HDD, 7200 rpm; or 144 TB, HDD, 7200 rpm |
| RAID level | 6 |
| RAID capacity (total) | 88 TB, or 132 TB |
| RAID capacity (usable) | 81.95 TB, or 122.92 TB |
| Hot-swap drive bays | 24 |
| Ports | |
| Ethernet | 2 × 10 GbE |
| IPMI | Yes |
| Cooling | |
| Processor | Passive heat sink |
| Chassis | 2 fans @ 6700 rpm each; 3 fans @ 7000 rpm each |
| Power supply | |
| Output | 1280 W (redundant) |
| Voltage | 100–240 V |
| Frequency | 50–60 Hz |
| Physical specs | |
| Chassis | 4U |
| Width | 17.2 in. |
| Depth | 26 in. |
| Height | 7 in. |
| Weight | 75 lb. (case) |
