Backup & Disaster Recovery appliance 4500
Not available for purchase. Not supported.


Â
 |  |
---|---|
End-of-life | Â |
End of sales | Dec 31, 2016 |
Hardware warranty 1 | Standard – 3 years from the date of purchase. Extended – 5 years from the date of purchase. |
End of software support 2 | Dec 31, 2021 |
Processor | Â |
Model | Intel Xeon E5620 |
Base frequency | 2.4Â GHz |
Number of cores | 4 |
Upgrade | N/A |
Memory | Â |
Size | 48Â GB |
Type | DDR3, ECC, REG |
Frequency | 1600Â MHz |
Upgrade | N/A |
Storage | Â |
Catalog drive capacity | 480Â GB, SSD |
Data drive capacity (raw) | 48Â TB, HDD, 7200Â rpm; or 72Â TB, HDD, 7200Â rpm; or 96Â TB, HDD, 7200Â rpm |
RAID level | 6 |
RAID capacity (total) | 44Â TB, or 66Â TB, or 88Â TB |
RAID capacity (usable) | 40.97Â TB, or 61.46Â TB, or 81.95Â TB |
Hot-swap drive bays | 24 |
Ports | Â |
Ethernet | 6 × 1 GbE |
IPMI | Yes |
Cooling | Â |
Processor | Active heat sink with fixed fan @ 7800Â rpm |
Chassis | 2 fans @ 6700Â rpm each; 3 fans @ 7000Â rpm each |
Power supply | Â |
Output | 1200Â W (redundant) |
Voltage | 100–240 V |
Frequency | 50–60 Hz |
Physical specs | Â |
Chassis | 4U |
Width | 17.2Â in. |
Depth | 26Â in. |
Height | 7Â in. |
Weight | 75Â lb. (case) |
Hardware warranty applies as follows:
If warranty is active, we replace hardware parts at our expense.
If warranty has ended, but hardware parts are still commercially available, we may replace them at your expense (including shipping).
If warranty has ended and hardware parts are not commercially available, we recommend hardware refresh.
Unless there is an active, previously signed support contract. ↩
