Not available for purchase. Supported in terms of both hardware and software.
| End-of-life | |
| End of sales | Jul 1, 2022 |
| Hardware warranty 1 | Standard – 3 years from the date of purchase. Extended – 5 years from the date of purchase. |
| End of software support 2 | Jul 1, 2027 |
| Processor | |
| Model | Intel Xeon E5-1650 v4 |
| Base frequency | 3.6 GHz |
| Number of cores | 6 |
| Upgrade | Up to 18 cores @ 2.1 GHz |
| Memory | |
| Size | 128 GB |
| Type | DDR4, ECC, REG |
| Frequency | 2666 MHz |
| Upgrade | Up to 256 GB |
| Storage | |
| Catalog drive capacity | 480 GB, SSD |
| Data drive capacity (raw) | 36 TB, HDD, 7200 rpm; or 48 TB, HDD, 7200 rpm; or 72 TB, HDD, 7200 rpm; or 96 TB, HDD, 7200 rpm |
| RAID level | 6 |
| RAID capacity (total) | 30 TB, or 40 TB, or 60 TB, or 80 TB |
| RAID capacity (usable) | 27.93 TB, or 37.25 TB, or 55.87 TB, or 74.5 TB |
| Hot-swap drive bays | 12 |
| Ports | |
| Ethernet | 2 × 10 GbE |
| IPMI | Yes |
| Cooling | |
| Processor | Passive heat sink |
| Chassis | 3 fans @ 7000 rpm each |
| Power supply | |
| Output | 920 W (redundant) |
| Voltage | 100–240 V |
| Frequency | 50–60 Hz |
| Physical specs | |
| Chassis | 2U |
| Width | 17.2 in. |
| Depth | 25.5 in. |
| Height | 3.5 in. |
| Weight | 55 lb. (case) |
-
Hardware warranty applies as follows:
-
If warranty is active, we replace hardware parts at our expense.
-
If warranty has ended, but hardware parts are still commercially available, we may replace them at your expense (including shipping).
-
If warranty has ended and hardware parts are not commercially available, we recommend hardware refresh.
-
-
Unless there is an active, previously signed support contract. ↩
